Below is a table representing a segment of Permabond's complete line of Single-Part Epoxy Adhesives. Contact a technical representative at Permabond to discuss your specific application requirements. We will be able to recommend the most suitable adhesive for your application.
Grade
(Click grade number for TDS)
Description
Viscosity mPa.s (cP)
Fixture Time (low power 4mW/cm lamp)
Tensile Strength
MPa (psi)
UV610
High strength bonding for glass to metal.
800-1000
11 sec.
17 (2500)
UV620
General purpose, optically clear. Ideal for glass bonding.
2000-3000
5 sec.
16 (2300)
UV625
Non-drip for larger gaps and vertical applications. Ideal for glass bonding.
Gel
5 sec.
16.5 (2400)
UV630
Low viscosity, plastic bonding.
200-300
6 sec.
14 (2000)
UV632
Low viscosity, plastic bonding, excellent adhesion to acrylic.
200-300
10 sec.
13 (1900)
UV640
Medium viscosity, plastic bonding.
3000-4000
7 sec.
13 (1900)
UV648
Medium viscosity, plastic bonding. excellent adhesion to acrylic.
Gel
10 sec.
11 (1600)
UV670
Flexible for metal and metalized plastics.
2000-3000
7 sec.
12 (1700)
UV7141
UV and anaerobic curing. For bonding ceramic coated glass, mirrors, glass and metal.
